Electric - Griddle Pan- 6-90 with Swing Door

$0.00

Model No: HA-NEGP 6-90

Product Details

Modular electric fryer with 900 mm depth for double basket use and heated with 2 x 13.5 kW incoloy heaters. Equipped with swing door. Usable for deep frying. Made of AISI 304 with 2 mm top thickness, temperature controlled, fully welded double fryer tank for two basket with separate oil capacity of 14 liters each, includes tank cover, oil drain kit, crumb filter and hook for lifting heater

Powered with 7.8 kW SSS heaters.
Cooking area of 490 x 510 x 100 mm.
Fully-welded griddle with radius constructed of AISI 420 with thickness of 20 mm, preventing rust.
Includes nylon plug to seal the drain and to cook liquid products.
Temperature control from 50 degree Celcius to 300 degree Celcius.
Thermal-cut off when overheated.
Cooking Surface- Cooking zones : 25 liters, 490 x 510 mm
Heating zones : 1
Control type : Modulating temperature control
Electrical Supply Data
Total connected load : 7.8 kW
Voltage : 400V, 3NPE AC /50-60Hz
Recommended fuse : 13 A (slow)
Net Weight : 114 kg
Dimensions: 600 x 900 x 850/880 mm
